Description
Features:
• Stored height of 5' 3.5"
• Lifts up to 800 lb (360 kg)
• 16' 3" Height
• No tools required, no loose hardware
• Mast hold-down secures mast for safe transport
• Pulley Guards: Designed to prevent load lines from slipping off
• Roller Wheels: Helps to roll into trucks or vans
• Cable feeds inside mast, removing exposed cable from near the operator’s face
• Sumner-built Winch Highly reliable, singlespeed winch uses idler roller to feed cable evenly on the drum to avoid cable flats. Handles are removable when not in use.
• Reversible Forks: Using plunger pins, forks remove and reverse easily for added height or to ceiling.
• STABILIZERS NOT INCLUDED
Specifications:
• Height Stowed: 63 in.
• Length Stowed: 34 in.
• Length operating: 73 in.
• Base Width: 31.25 in.
• With with stabilizer legs: 74 in.
• Ground Clearance: 2.5 in.
• Load Height minimum: 6 in.
• Maximum Height Forks Down: 14'3 in.
• Maximum Height Forks Reversed: 16' 3 in.
• Weight: 365 lbs
• Stored height of 5' 3.5"
• Lifts up to 800 lb (360 kg)
• 16' 3" Height
• No tools required, no loose hardware
• Mast hold-down secures mast for safe transport
• Pulley Guards: Designed to prevent load lines from slipping off
• Roller Wheels: Helps to roll into trucks or vans
• Cable feeds inside mast, removing exposed cable from near the operator’s face
• Sumner-built Winch Highly reliable, singlespeed winch uses idler roller to feed cable evenly on the drum to avoid cable flats. Handles are removable when not in use.
• Reversible Forks: Using plunger pins, forks remove and reverse easily for added height or to ceiling.
• STABILIZERS NOT INCLUDED
Specifications:
• Height Stowed: 63 in.
• Length Stowed: 34 in.
• Length operating: 73 in.
• Base Width: 31.25 in.
• With with stabilizer legs: 74 in.
• Ground Clearance: 2.5 in.
• Load Height minimum: 6 in.
• Maximum Height Forks Down: 14'3 in.
• Maximum Height Forks Reversed: 16' 3 in.
• Weight: 365 lbs
